COR-I5TRF

Cortex 5MP AHD Camera with IR and 2.8mm wide angle lens

AHD | TVI | CVI | 5MP & 4MP | 2K HD Camera

Build the best surveillance system with premium cameras and recorders from Cortex. These AHD/TVI outdoor turrets have the Cortex patented Dragonfire infrared illumination system that insures long distance viewing in extreme low light conditions and total darkness. Whether the project calls for wide angle views or rugged metal housings, these models are a perfect fit. Installers will love the selectable output and OSD controls via UTC on the DVR interface. Image changes are easily accessible during installation and the mini-joystick for adjusting the on-screen display (OSD) menu in the cable harness. This provides 2 ways to access the programming menus. Best in class vision is at your fingertips.

Outdoor Rugged metallic turrets from Cortex. These AHD/TVI outdoor turret domes have the Cortex Dragonfire infrared illumination system that insures long distance viewing in extreme low light conditions and total darkness. Whether the project calls for wide angle views or rugged metal housings, these models are a perfect fit. Installers will love the selectable output and OSD controls via UTC on the DVR interface. Image changes are easily accessible during installation and the mini-joystick for adjusting the on-screen display (OSD) menu in the cable harness. This provides 2 ways to access the programming menus. Best in class vision is at your fingertips.

Send Me Prices

Main Features

  • 1/2.7” CMOS
  • Night Vision 100 (feet)
  • 2.8mm fixed focus mp rated lens
  • IR Cut Filter
  • Features OSD Menu
  • DWDR
  • 5MP 2592(H) × 1944(V)
  • Ultra High sensitivity
  • Includes interline HDR image synthetic algorithm that expands Dynamic Range up to 100dB
  • Stealth Infrared cover for aesthetic style
  • High signal to noise ratio SNR:39dB
  • Sensitivity:2800mV/Lux
  • Min. Illumination: Color 0.05lux B/W with IR 0 Lux
  • Improved infrared quantum efficiency in the range of 850nm-940nm
  • Shutter Speed Control : OSD
  • AGC Adjustment : OSD
  • White Balance : ATW /
  • NTSC / PAL
  • 5MP AHD / 5MP TVI @20fps
  • 4MP AHD / 4MP TVI @30fps
  • 2MP CVI @30fps
  • 960H Analog legacy @30fps
